120kW air cooling DC charger
GPEV120-BG102-S2C
GPEV120-BG102-S2C
Product Advantages
Wide range constant power
High efficiency and low consumption
Nano-level dustproof
High-waisted waterproof immersion
Original design
Optional rain shield
Reliable quality
Free platform
Worry-free insurance
Low-cost station construction
Product parameters
| Model | GPEV120-BG102-S2C |
| Dimensions W×H×D | 888*1715*532mm (without rainproof) |
| Weight | ≤220Kg(with 4 power modules) 160Kg(without power module) |
| Charging Gun | Double guns |
| Extension cable | 6m, optional length on request |
| IP level | IP54 |
| Power modules | GPR102100B*4 |
| Input Voltage | 380±15%Vac |
| Cooling | Fan cooling |
| Max Current | 250A(Single gun) 200A(Double-gun) |
| Power | 120kW |
| Voltage with constant power | 300-1000V |
| Voltage range | 200-1000V |
| Efficiency | 95% |
| Altitude | 2000m |
| Operation temperature | -20~50℃ |
| RH | 5~95% |
